Description
Introducing the JAM² 8.0 – Conquer New Mountains with Confidence!
• LIMITED EDITION BOSCH CX RACE E-DRIVE & 750 WH BATTERY for dynamic acceleration and enduring power.
• 160 MM FOX 36 FACTORY FORK & 150 MM FOX X PERFORMANCE SHOCK for smooth and controlled rides.
• SHIMANO XT 1X12 PLUS DT SWISS H1900 WHEELS for precise shifting and reliable performance.
Experience the JAM² 8.0, crafted for conquering mountains with the lightweight Bosch Performance Line CX Race e-drive, delivering impressive 85 Nm and 400% pedal power support.
The integrated slide-out battery enhances convenience, while the Bosch System Controller, wireless Mini Remote, and Kiox display offer seamless control.
Enjoy maximum trail fun with the JAM² 8.0’s balanced geometry, carbon frame, and low stand-over height, ensuring stability and nimble handling on diverse terrains.
Adapt the head angle to your preference for personalized riding.
Navigate with full control using F.O.L.D. optimized suspension, tacky 29″ tires, and dependable brakes.
Elevate your mountain biking adventures with the JAM² 8.0 – your ultimate companion for tackling trails with precision and confidence.
SPECIFICATION
FRAME
Carbon front triangle, aluminium rear triangle, 150 mm F.O.L.D.
GEN2 kinematics, 148×12 mm thru axle, internal cable routing, post mount 203 mm
FORK
FOX 36 Float Factory 29, Grip 2, 110 x 15 mm, 44 mm rake
TRAVEL OF SUSPENSION FORK
160 mm
SHOCK
FOX Float X Performance, 210/55 mm, hardware: 25.0 x 8.0, no Bushing
MOTOR
Bosch Performance Line CXR Smart System, 36 V / 250 W / 85 Nm
BATTERY WATT-HOURS
750 Wh
BATTERY AMPERE HOURS
20.8 Ah
DISPLAY
Bosch System Controller + Mini Remote + Kiox 300
SHIFTER
Shimano Deore XT M8100, 12-speed
REAR DERAILLEUR
Shimano Deore XT M8100, 12-speed
SPROCKET
Shimano SLX M7100, 12-speed
CHAIN
Shimano SLX CN-M7100, 12-speed
CRANKSET
RaceFace Aeffect R e-Optimized Bosch G4
TRANSMISSION OF DRIVE
front: 36, rear: 10-51
BOTTOM BRACKET
Integrated in Drive Unit
HANDLEBAR
RaceFace Atlas 35, aluminium, 820 mm, rise: 35 mm, backsweep: 8°
STEM
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium
HEADSET
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S.
Integrated, 1.5/1.8″ angle headset
SADDLE
Fizik Terra Aidon
SEATPOST
Post Moderne dropper post PM-214, 34.9 mm
BRAKE CALIPER
Shimano XT M8120, 4 piston
BRAKE LEVER
Shimano XT M8120, 4 piston
BRAKE
Disc
WHEELSET
DT SWISS H1900, 30-622, 15×110 mm / 12×148 mm
TIRES
Schwalbe Magic Mary, 2.6 Super Trail Soft, 65-622
REAR TIRE
Schwalbe Big Betty, 2.6 Super Trail Soft, 65-622
GEARS
12
BIKE WEIGHT INCL.
BATTERY (KG)
23.4
SIZE
39, 42, 44, 46.
